GSA Golf VisTrak SCX Lite — Ceiling-Mounted Golf Launch Monitor

Experience professional-grade ball and club tracking at the most accessible price in golf simulation. The VisTrak SCX Lite is the world's lowest-priced overhead-mounted, high-speed stereo camera launch monitor — delivering the same comprehensive data capture and post-shot video playback as systems costing three to ten times more. Built by GSA Golf in Naples, Florida, the SCX Lite mounts to your ceiling and uses two high-speed cameras with infrared illumination to photograph every detail of your ball and club at impact. All data is fully user-verifiable through frame-by-frame slow-motion video, so you can see your real launch angles, club face position, and ball spin with your own eyes — not just trust a number on a screen. Whether you're fine-tuning your swing on the driving range or playing a full round on your favorite virtual course, the SCX Lite brings overhead camera tracking within reach.

Features

• Dual high-speed stereo cameras (up to ~1,500 fps) for precise ball and club tracking from overhead
• Hi-powered narrow-beam IR (infrared) lighting for clean, glare-free image capture
• Fully user-verifiable data — see real launch angle, ball path, spin, and club face angle in slow-motion playback
• Post-shot video playback after every shot, including a dedicated ball-spin video window
• Laser ball-placement guide — automatically switches off when the ball is detected in the launch zone
• Acrylic light-bar "ball detected / system ready" indicator for instant visual feedback
• Detects full shots, chips, and putts with complete data capture
• Works for both right- and left-handed players
• Lightweight light-bar design — no bulky case; cameras mounted on a slim ceiling bar
• Compatible with all major sim software: GSPro, E6 Connect, The Golf Club (TGC), ProX, Creative Golf 3D, and GSA software
• No subscription fees — one-time purchase
• No specialty proprietary balls required — use any ball with a logo or TaylorMade Pix balls
• Fully modular and upgradeable — add cameras at any time to create an SCX Pro, EVi, or LX2 configuration
• 1 FREE 18-hole golf course included with GSA software
• Compact light-bar form factor (ceiling mounted) — significantly smaller and lighter than the cased SCX Pro

Data Measured

• Ball Speed
• Ball Path (HLA)
• Ball Launch Angle (VLA)
• Club Speed
• Club Path
• Club Face Angle

Calculated

• Ball Spin
• Spin Axis

Included

• 2 High-Speed Cameras on Light Bar
• Hi-Powered IR Narrow-Beam Lighting
• GSA Software Suite
• 1 Free Golf Course
• USB3 Cables & Power Supply


Minimum PC Requirements

• Intel i5 or above processor (desktop gaming PC — no AMD, no laptops, no custom-built PCs)
• 8 GB RAM
• NVIDIA 1070 GPU or equivalent
• 25 GB hard drive space
• Windows 10 or 11
• 2× USB 3.1 (10 Gbps) ports (cameras must connect directly — no hubs)
• Internet connection (required for third-party game software)

SCX Lite vs. SCX Pro

The SCX Lite and SCX Pro share identical tracking functionality: the same dual high-speed cameras, the same data outputs, the same software compatibility, the same post-shot video playback, and the same putt detection. The differences are entirely in housing, lighting, and included extras. The SCX Lite is the SCX Pro's tracking brain in a budget skin. You get the same cameras, the same data, the same software — you're just not paying for the enclosed case, the internal IR panel lighting, and the track lights.
